Cooling circuit WZS
Designed for cooling solid fuel boilers. Mounted in closed central heating systems.
Technical parameters WZS-2
- for boilers with the power up to: 34 kW
- cooling circuit surface: 0,17 m2
- min. cooling water flow: 15 l /min
- weight: 7 kg
Connections:
- heating water outlet:
1 1/2" (external thread)
- cooling water and sawage:
1/2" (external thread)
Dimensions:
- height (with connections): 330 mm
- width: 140 mm
- depth: 180 mm (140 mm + 40 mm connection)
This cooling circuit can be used for boiler up to 32 kW. For boilers above 34 kW you may use a WZS-3 or WZS-4
Technical parameters WZS-3
- for boilers with the power up to: 34-70 kW
- cooling circuit surface: 0,61 m2
- min. cooling water flow: 15 l /min
- weight: 17,5 kg
Connections:
- heating water outlet:
fi 50mm (external thread)
Dimensions:
- height : 495 mm
- width: 220 mm
Technical parameters WZS-4
- for boilers with the power up to: 70-120 kW
- cooling circuit surface: 1,11 m2
- min. cooling water flow: 15 l /min
- weight: 27,5 kg
Connections:
- heating water outlet:
fi 50mm (external thread)
Dimensions:
- height : 595 mm
- width: 240 mm
